Multiple Retention Floating Boom |
|
| |
|
|
| |
With the suitable combination of net and special synthetic fabrics in the centre of immersion of the construction, the floating boom of multiple retention constitutes the solution to the confrontation of various forms of pollution.
The high level of durability of the materials, the hydrodynamic design and the adapted to each condition manufacture make it a floating boom of permanent installation, with a long life-span in extreme meteorological conditions that comes to give solutions to pollution from petroleum products, other humid sewages, seaweed and floating litter.
|
|
| |
|
|
| |
|
|
| |
|
|
| |
Technical Data |
|
| |
|
|
| |
Technical Field |
|
| |
| Total height |
1.50m |
| Freeboard |
0.50m |
| Draught |
1.00m |
| Weight |
6.00 Kgr/m |
| Tensile strength (ropes only) |
9.8 tn |
| Part lengths |
25m και 50m |
| Color |
Orange & White |
|
|
| |
|
|
| |
| Construction Part |
| Technical Characteristics |
|
|
| |
| Net |
Thread composition |
Polyamide - dyneema |
| Fabric |
Height |
55cm total part height , 25cm freeboard, 30cm draught |
| Material or Composition |
Double coated PVC
UV-stabilized – antibacterial
|
| Tensile strength |
Tensile strength:
Warp: 4000*2=8000N/50mm
Weft: 3500*2=7000N/50mm
Tear strength:
Warp: 600N*2 =1200N
Weft: 500N*2 =1000N
|
| Welding-Sewing |
High frequency welding and double sewing stitches with the net |
Supporting
and floating bars |
The support and endurance base of Okeanis Products |
Placed per meter |
| Connectors and Mooring Stabilizers |
Double coated plastic bars with stainless steel mooring connectors |
Placed in distances according to mooring and connecting |
| Ballasts |
Upper and lower ballast |
High resistance ropes, according to constructions characteristics |
| Down part |
Weight 2,2Kgr/m |
|
|
| |
|
|
| |
|
|
| |
Additional Information |
|
| |
|
|
| |
Multiple Retention Floating Boom Advantages |
|
| |
The floating boom Okean-NetBoom is designed for permanent use and for the retention of oil, foam, vessels, seaweeds, litter and debris.
The combination of fabric and net reduces the floating boom resistance, and it also distributes the water forces evenly, therefore increasing the boom durability and effectiveness. |
|
| |
|
|
|
 |
 |
|
|
| |
|
 |
